MOI+ , the successor of MOI DVB-S2 streaming box, is another innovative streaming box from TBS.
MoI+ features Marvell 88F6282 processor and runs Linux OS, it’s a more powerful streaming solution
for home users and business users who are looking for cost- effective solution for small hotel,
hospital, educational IPTV projects.
MOI+ is designed for sharing live TV & radio contents to multi-devices in your house or workplace through
Ethernet or wireless network. With a DVB tuner connected, it enables you to receive live TV & radio
contents - both FTA (Free to Air) channels and Pay TV (encrypted) channels , and further stream
them to the following client devices: PC, Tablet, Smartphone, iDevices (iPhone, iPad, iPod) or
Sony Playstation 3, using a client device, it’s easy to access the manageable web UI for DVB
tuner settings and firmware update.
MOI+ provides more flexibility, it’s not limited to DVB-S2, it allows you to connect one PCI Express
tuner card with the main board through the PCIe adapter, no matter you need DVB-S2 tuner for satellite
TV, DVB-T2/T tuner for terrestrial TV, or DVB-C tuner for cable TV, you can find the right one from
a wide range of TBS PCIe tuner cards. For more details about compatible PCIe tuner cards, click here.
- System
-
SoC: Marvell 88F6282 1.6 GHz
CPU: Sheeva CPU core V5TE ARM
RAM: 1GB DDR3
Flash: 512MB NAND Flash - Interface
-
2x USB 2.0
1x SATA port
Ethernet: 100/1000M Gigabit Ethernet
Protocol: HTTP, UDP, RTP, TCP
OS: Linux - Preinstalled software
-
Tvheadend, VDR, Mumudvb, DVBlast,
szap, tzap, czap, dvbdate, dvbnet, dvbscan,
dvbsnoop, dvbtraffic, dvbscan, scan-s2,
szap-s2, dst_test, telnet, ssh, sftp, samba,
oscam - Client end support
- PC: Windows, Linux, Mac
Tablet: Android, iOS
Smartphone: Android, iOS - DVB tuner support
-
DVB-S2/S: 1 tuner card
DVB-T2/T: 1 tuner card
DVB-C/J.83B: 1 tuner card
Note: The 2x mounting brackets are not included in the package of MOI+, they are offered as optional accessories.
- Which DVB tuner card to use
-
-step 1. choose DVB standard:
You need to know what DVB standard(s) can be used in your region, for example, if you are located in Germany, you can use DVB-S2 for satellite TV, if you live in the UK, you probably want to use DVB-T2/T for terrestrial TV (Freeview).
-step 2. Choose a tuner card:
After you decide for a DVB standard, for example DVB-S2, there are a few cards to choose from single, dual or quad tuner card, tuner card with or without CI slot. If you are going to build a streaming server system and need encrypted TV channels, it’s recommended to use the dual tuner dual CI card TBS6991SE. If you need only FTA (free to air) channels, you can use the TBS6991SE, TBS6982 or TBS6985.
Products works with MOI+ :
DVB-S2:
TBS6922, TBS6982, TBS6983, TBS6985, TBS6928, TBS6928SE , TBS6991, TBS6991SE, TBS6904
DVB-T2 :
TBS6221, TBS6285, TBS6205, TBS6290se
DVB-C :
TBS6618, TBS6680
More information or support needed? Click here
