TBS2956 Industrial Media server

TBS2956 is the latest generation of digital TV streaming server from TBS Technologies International Ltd. It is powered by AMD Embedded G-Series SoC, equipped with 4GB DDR3 and 30G mSATA SSD and the mini Fanless design make it available with a wall mount or DIN-rail mount ensuring maximum flexibility and upgradeability. TBS2956 media server is ideal for economic IPTV solution in coffee shop, exquisite bar, restaurant or vehicle carrier etc.

  • Description
  • Specification
  • Picture
  • User Guide
  • Download

Features:

  • Industrial Fanless Embedded Computer
  • Available for Wall Mount or DIN-Rail Mount
  • 2 PCI-e interface for different TBS DVB standard cards
  • Apply to Economic Mini IPTV Solution
  • IPTV Streaming server and CMS server

What can TBS2956 do?

  • Digital TV Channels Capturing and Streaming
    • TBS2956 server delivers video content over the Internet to a user with a computer, smartphone, or other connected device.
    • Loaded with any of TBS Digital TV Tuner card, TBS2956 server captures SD/HD Live channels from satellite TV, Terrestrial TV, Cable TV.
    • Embedded variety of streaming software: TVheadend, VDR, MuMuDVB, DVBlast, TBS2956 is available to streaming channels with protocol of UDP/RPT or http.
    • The Mini Fanless design, TBS2956 server is available with a wall mount, the idea choice of outdoor IPTV system, for example, The Vehicle IPTV system.
  • All-in-ONE IPTV headend server for small size IPTV solution
    • TBS2956 server is an all-in-one IPTV headend for receiving and multicast/unicast streaming of satellite, terrestrial, and cable TV channels; uploading, storing, encoding, managing and distributing movies in IP networks upon request; capturing and transmission on-line video streams over IP networks and Internet.
    • Embedded Kylone Panel software provides graphical user interface for the IP set-top boxes, management of tariff plans and providing access to IPTV services for users. Ideal for economic IPTV solution in coffee shop, exquisite bar, restaurant or vehicle carrier etc.
