    TBS2604V2 4K UHD HD H.265 & H.264 HDMI Video Encoder

    TBS2604V2 is a 4K UHD H.265 & H.264 HDMI Video Encoder, capable of up to max 3840 x 2160P@30fps. It supports to encode with dual streams and streaming via IP,the main stream and the sub-stream can be encoded into different resolutions, bit rates, and then adapted to different terminals.

    TBS2604V2 HDIM Video encoder supports H.265 encoding, which is ideal choice for customers who need lower bit rate video transfer over LAN or WAN networks – often due to internal network limitations, whilst maintaining high quality video.

    TBS2604V2 is coupled with Web UI managing system and Telnet remote access, which provide users flexible choices to control the encoder at anytime and anywhere.


    • 3840x2160p@30hz In and 3840x2160p@30fps encode maximum
    • H.264/H.265 Encode
    • AAC-HE, AAC-LC, G.711 audio encoding
    • Bitrate of output video stream is adjustable from 500kbps to 20Mbps
    • Support HTTP, HLS(m3u8), RTSP, UDP Unicast & Multicast, RTMP/RTMPS, SRT
    • Support inserting Logo, Text (OSD overlay)
    • PCR adjustment
    • Support HDCP 1.4
    • Flexible and friendly webpage control
    • Stable and effective, support 7 x 24h working time


    3840x2160p@30fps (H.265/H.264), 4K encode

    Real-time encoder supporting resolutions up to 4K with H.264/H.265 encoding.

    http/rtsp/udp/unicast & multicast/srt (caller mode, listener mode)/rtmp/rtmps/hls m3u8/rtmp compatible with different terminals

    Flexible and friendly webpage control, easy to check and control the status of the device
