TBS2611 1 HDMI + 2 AV/CVBS Video Encoder

Application

• Digital TV Broadcasting System
• IPTV & OTT system
• Digital Signage Project
• Remote Video Conference
• Live Streaming
• Head-end system of Digital TV branch network

Key Features

• 1920x1080p/1920x1080i/1280x720p/720*576i/720*576p/640*480i resolutions
• Support H265 main profile /H.264 baseline profile / main profile/ high profile
• Support multiple devices display on a computer at the same time
• Support SDI / VGA / CVBS convert to HDMI input, Support audio gain, be able to turn volume individually
• Support RTSP/RTP/RTMP/HTTP/ONVIF/UDP unicast and multicast protocol (RTMP support adding users and changing passwords),
• Support DHCP/, ONVIF protocol, support HD Blue-ray
• Support Main TS stream and the sub-TS stream use in different network protocols for transmission (multi-rate multi-protocol support)
• Rate Control CBR / VBR 16KBIT / S ~ 12MBIT / S
• Transmission: TCP, UDP, 1000M (RJ45 Ethernet port duplex)
• Support streaming add watermark (OSD), XY axis, the font can be set;
• Transmission: TCP, UDP, 1000M (RJ45 Duplex network port)
• Image settings: contrast ratio, brightness, tones, saturation, noise detection, sharpness, filtering
• Support build-in or external methods, support left and right sound channel, Support audio gain, be able to turn volume individually
• Support coding without video signal;
• Complete the setting effect immediately, don’t need to restart
• Support one-key recovery of the default configuration
• Support set-top box decoder
• Low power consumption design

Specifications
