TBS2802 is a professional 2 channels 4K HDMI Video Encoder that enables high-quality content streaming and display. It supports maximum of 4K@60Hz HDMI input and can stream to popular online social media platform, such as YouTube Live, Facebook Live, Twitch or to a custom-specified RTMP/RTMPS servers. It compatible with HTTP/HLS(M3U8)/RTSP/RTP/UDP /Unicast & Multicast/SRT/RTMP/RTMPS, what's more, it supports multiple protocol outputs, up to 6 protocols at the same time.

TBS2802 supports to capture and record HD content in H.265/H.264 format from PlayStation and digital video cameras. Besides, with flexible web UI control, it can easily switch between channels and adjust configurations, offering better TV viewing experience.

Applications

• IPTV Servers
• Datacasting and monitoring
• Live TV Encoding and streaming
• Broadcast TV

Feartues

• Supports H.265/HEVC and H.264/AVC compression
• Supports up to 2 channels 4K@60Hz HDMI input
• Zero-latency HDMI loop-out, up to 4K@60Hz
• Controlled by user-friendly web UI
• Supports multiple streaming protocols, including HTTP/HLS(M3U8)/RTSP/RTP/UDP /Unicast & Multicast/SRT/RTMP/RTMPS

Why choose TBS2802

Supports 2 channels real 4K@60Hz encode

• 3840x2160p@60fps(H.265) , real 4K encode
• Capture & Deliver Live Video in 4K Ultra HD over Public Internet
• Real-time encoder supporting resolutions up to 4K with H.264/H.265 encoding.
• Efficient encoding leads to bandwidth savings, even at high resolutions.

Multiple protocol output

• Compliant with HTTP/HLS(M3U8)/RTSP/RTP/UDP /Unicast & Multicast/RTMP/RTMPS
• Each channels have multiple protocols for outputting

Friendly web UI for control

Reliable Web UI let you easy to setup and manage.

Specification
